FederalSignal
Model FSEX-HI-MOD Explosion Proof Synchronized Fire Alarm strobe light 150cd UL1971 - 24VDC, 3A surge current
Log in or Create an Account to see pricing and buy online.
Mounting options are sold separately:
Datasheet
Installation
Federal Signal’s Model FSEX-HI explosion-proof strobe light produces between 60 - 80 high-intensity flashes per minute. This warning light operates on 24VDC and is unique to the market because it covers an entire range of possible mounting configurations–including dome up. This light is designed for use in alarm notification systems and is compatible with fire alarm and suppression supervised control panels and power boosters.
The FSEX is UL Listed for Class I, Division 1, Groups C and D; Class II, Division 1,Groups E, F and G; Class I, Division 2,Groups A, B; and ClassIII. The FSEX-HI is UL and cUL listed, and Marine Rated.
The 24VDC FSEX-HI featuresa voltage in-rush limiting PCB design that provides greater compatibility with factory automation control systems and less electrical interference with in-rush sensitive devices.
The FSEX-HI is Type 4X rated; constructed to IP66. Corrosion resistance is achieved with a powder coat finish applied over the copper-free aluminum housing. Federal Signal’s Model FSEX-HI is rated at 150 candela per UL1971 and @ two million peak candela . The FSEX-HI can be paired with a pendant, ceiling or wall mount. For easy installation, the mounting box is first installed and the fixture is then threaded onto the mounting box, making the electrical connection. Electrical continuity is made when
five threads areengaged. The FSEX-HI-MOD contains a supervisory diode and four wire leads, for use in fire alarm applications.
The 24VDC FSEX-HI featuresa voltage in-rush limiting PCB design that provides greater compatibility with factory automation control systems and less electrical interference with in-rush sensitive devices.
The FSEX-HI is Type 4X rated; constructed to IP66. Corrosion resistance is achieved with a powder coat finish applied over the copper-free aluminum housing. Federal Signal’s Model FSEX-HI is rated at 150 candela per UL1971 and @ two million peak candela . The FSEX-HI can be paired with a pendant, ceiling or wall mount. For easy installation, the mounting box is first installed and the fixture is then threaded onto the mounting box, making the electrical connection. Electrical continuity is made when
five threads areengaged. The FSEX-HI-MOD contains a supervisory diode and four wire leads, for use in fire alarm applications.
Synchronize with the Federal Signal SSM module or by installing on an indicating circuit programmed with the System Sensor sync protocol. Federal Signal’s Model FSEX-HI is specifically designed for explosionproof atmospheres and/or corrosive environments. Because it is easy to install and requires very low maintenance, it is ideal for use in areas such as oil rigs, mines, refineries, and chemical plants.
