Federal Signal: FHEX

Class I Division 1 explosion-proof vibrating horn - 24Vdc, 99dB(A)

Federal Signal: FHEX
  • Federal Signal: FHEX
Accreditation
Accreditation image Accreditation image
Coding

NEC / CEC:
Class I Div 1 Group CD T6 Ta ≤ +40°C
Class II Div 1 Group EFG T6 Ta ≤ +40°C
Class III T6 Ta ≤ +40°C
Approvals

UL_Certificate_of_Compliance.pdf

CSFM_Listed.pdf

More from this collection
Federal Signal: FHEX

Federal Signal: FHEX

Class I Division 1 explosion-proof vibrating horn - 24Vdc, 99dB(A)
Description

Federal Signal’s Model FHEX Explosion-Proof Vibrating Horn produces a loud and distinctive tone by the electromechanical vibration of a diaphragm. This horn is designed for use in alarm notification systems and is compatible with fire alarm and suppression supervised control panels and power boosters.

The Model FHEX operates on 24Vdc and produces a very loud 99 dBa@10' (109dB(A) @1m).

Model FHEX is housed in a heavy duty, copper-free cast aluminum housing tapped for 3/4" conduit. The housing is sealed with red powder coat paint and utilizes a stainless steel diaphragm for long life.
Features
  • 24Vdc
  • Produces 99 dB(A)@ 0' (109 dB(A)@1m)
  • Supervisory diode and four wires
  • Cast aluminum housings
  • Duty cycle 5 minutes on – 5 minutes off
  • Indoor/outdoor use
  • CSFM Approved
  • UL and cUL for Class I, Division 1, Groups C and D; Class II, Division 1, Groups E, F, and G; Class III
  • Manufacturer warranty: 5 years
Approvals

UL_Certificate_of_Compliance.pdf

CSFM_Listed.pdf

Select product and buy
PART NUMBER: FHEX-024SMR
Quantity
$ 2,560.44 $ 3,755.30
Description

Federal Signal’s Model FHEX Explosion-Proof Vibrating Horn produces a loud and distinctive tone by the electromechanical vibration of a diaphragm. This horn is designed for use in alarm notification systems and is compatible with fire alarm and suppression supervised control panels and power boosters.

The Model FHEX operates on 24Vdc and produces a very loud 99 dBa@10' (109dB(A) @1m).

Model FHEX is housed in a heavy duty, copper-free cast aluminum housing tapped for 3/4" conduit. The housing is sealed with red powder coat paint and utilizes a stainless steel diaphragm for long life.
Features
  • 24Vdc
  • Produces 99 dB(A)@ 0' (109 dB(A)@1m)
  • Supervisory diode and four wires
  • Cast aluminum housings
  • Duty cycle 5 minutes on – 5 minutes off
  • Indoor/outdoor use
  • CSFM Approved
  • UL and cUL for Class I, Division 1, Groups C and D; Class II, Division 1, Groups E, F, and G; Class III
  • Manufacturer warranty: 5 years
