D1xB2X05

NEC Class / Zone
Class I Zone 1 AEx db IIC T4 Ta -55°C to +80°C (T5: +75°C)
Class I Zone 1 AEx db IIC T6 Ta -55°C to +60°C (DC only)
Zone 21 AEx tb IIIC T99°C Ta -55°C to +80°C

CEC Class / Zone
Ex db IIC T4 Ta -55°C to +80°C (T5: +75°C, T6: +60°C)
Ex tb IIIC T99°C Ta -55°C to +80°C

NEC / CEC Class / Div
Class I Div 1 Group ABCD T5 Ta -55°C to +80°C (T6: +70°C)
Class II Div 1 Group EFG T5 Ta -55°C to +80°C


D1xB2X10

NEC Class / Zone
Class I Zone 1 AEx db IIC T4 Ta -55°C to +80°C (AC: +65°C)
Class I Zone 1 AEx db IIC T5 Ta -55°C to +45°C
Zone 21 AEx tb IIIC T132°C Ta -55°C to +80°C (AC: T153°C +70°C)

CEC Class / Zone
Ex db IIC T4 Ta -55°C to +80°C (AC: +65°C) T5 to +45°C
Ex tb IIIC T132°C Ta -55°C to +80°C (AC: T153°C +70°C)

NEC / CEC Class / Div
Class I Div 1 Group ABCD T4 Ta -55°C to +80°C (AC: +70°C)
Class I Div 1 Group ABCD T4A Ta -55°C to +70°C (AC: +55°C)
Class I Div 1 Group ABCD T5 Ta -55°C to +50°C
Class II Div 1 Group EFG T4 Ta -55°C to +80°C (AC: +40°C)


D1xB2X15

NEC Class / Zone
Class I Zone 1 AEx db IIC T3 Ta -55°C to +80°C (AC: +65°C)
Class I Zone 1 AEx db IIC T4 Ta -55°C to +65°C
Zone 21 AEx tb IIIC T132°C Ta -55°C to +80°C (AC: T153°C
+70°C)

CEC Class / Zone
Ex db IIC T3 Ta -55°C to +80°C (AC: +70°C)
Ex db IIC T4 Ta -55°C to +65°C
Ex tb IIIC T132°C Ta -55°C to +80°C (AC: T153°C +70°C)

NEC / CEC Class / Div
Class I Div 1 Group ABCD T3C Ta -55°C to +80°C (DC only)
Class I Div 1 Group ABCD T4 Ta -55°C to +55°C (AC: T4A
+55°C)
Class II Div 1 Group EFG T4 Ta -55°C to +80°C (AC: +40°C)
Class III Div 1 Ta -55°C to +80°C (AC: +40°C)


D1xB2X21

NEC Class / Zone
Class I Zone 1 AEx db IIC T3 Ta -55°C to +80°C (AC: +60°C)
Class I Zone 1 AEx db IIC T4 Ta -55°C to +45°C (AC +50°C)
Zone 21 AEx tb IIIC T181°C Ta -55°C to +80°C (AC: T153°C
+60°C)

CEC Class / Zone
Ex db IIC T3 Ta -55°C to +80°C (AC: +60°C)
Ex db IIC T4 Ta -55°C to +45°C (AC: +50°C)
Ex tb IIIC T181°C Ta -55°C to +80°C (AC: T153°C +60°C)

NEC / CEC Class / Div
Class I Div 1 Group ABCD T3B Ta -55°C to +80°C (DC only)
Class I Div 1 Group ABCD T3C Ta -55°C to +75°C (AC: +60°C)
Class I Div 1 Group ABCD T4 Ta -55°C to +50°C (AC: T4 +55°C)
Class II Div 1 Group EFG T3C Ta -55°C to +40°C (AC: T4)
Class III Div 1 Ta -55°C to +80°C (AC: +40°C)
